Data Presentation

Data Presentation

The field data is put into graphs that can be tailored to fit the customer specifications. Field data is sent to company representatives daily in PDF format and can be distributed to multiple parties. The final survey plots can be done in hard copy and/or electronic copy and are normally sent to the customer 7-14 days after completion of project. The following examples show different ways the CIS data is presented.


Information Format:
Two Line Plot

Overview:
Two line plots give a basic overview of CP on pipeline.

Click on the thumbnail to see a closeup of the information.

interrupted1T



Information Format:
Three Line Plot

Overview:
Three line plots have depolarized reading to show 100 mv shift criteria and have exception tables include with out of criteria reading highlighted.

Click on the thumbnail to see a closeup of the information.

threeline1T



Information Format:
Exception Tables

Overview:
The exception table gives a summary of areas not meeting criteria. It also includes a GPS location for every exception.

Click on the thumbnail to see a closeup of the information.

exception1T



Information Format:
Satellite Imagery

Overview:
Hanson Survey & Design is now pleased to offer integrated CIS / GP satellite imaging. This service allows the customer to view their Row and CIS at the same time. This real time picture will enable the client to better plan remediation projects and also have an idea of encroachment by other pipelines, the public, or utilities.

Click on the thumbnail to see a closeup of the information.

threeline1T



Information Format:
Exception Graph

Overview:
This graph shows areas not meeting criteria.

Click on the thumbnail to see a closeup of the information.

exception2T
